Technical Specifications Durostone® EPX -M S11
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Density | ISO 1183 | g / cm3 | 2,1 |
| Flexural strength ┴ | ISO 178 | MPa | 600 |
| Flexural strength ┴ +150°C | ISO 178 | MPa | 300 |
| Modulus of elasticity in flexion ┴ | ISO 178 | MPa | 30000 |
| Compressive strength (tangential) | ISO 604 | MPa | 450 |
| Compresive strength (axial) | ISO 604 | MPa | 90 |
| Compressive strength (radial) | ISO 604 | MPa | 90 |
| Tensile strength II RT | ISO 527 | MPa | 600 |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Flammability | UL 94 | / | V0 ( > 8mm) |
| Temperature index | IEC 60216 | T.I. | 180 |
| Insulation class | IEC 60085 | / | H |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Electric strength 90°C under oil ┴ | IEC 60243 | kV / mm | 5 |
| Electric strength 90°C under oil II | IEC 60243 | kV/25mm | 35 |
| Comparative tracking index | IEC 60112 | CTI | 600 |
