Sustarin® C grey

POM-C

The construction material for many applications

Sustarin^® C is the brand name for semi-finished products and profiles made from polyacetal copolymer. The special feature of Sustarin^® C is the ideal combination of strength, rigidity, and toughness, which is due to the structure of the product. Due to its high crystallinity, Sustarin^® C is stiffer and stronger than other thermoplastics, especially in the temperature range of -50°C bis +100°C.

iron grey, similar RAL 7011blue grey, similar RAL 7031stone grey, similar RAL 7030tarpaulin grey, similar RAL 7010

All colors

rodsheettubular bar

Characteristics

Chemical resistant
Low moisture absorption
High abrasion resistance
Low creep tendency
Good machinability
Good electrical properties
Good dielectric properties
Good dimensional stability
Good sliding properties

Industries

Application Examples

ROV 部件

遥控潜水器（ROV）不断被用于在越来越深的水域下工作。为助一臂之力，我们提供了很多耐腐蚀的关键部件用来组装 ROV。其中包括本身具有浮力的 Polystone® P（PP）和 Polystone® D（PE-HMW）材料，用以制作侧框架。而电子元件箱则采用 SUSTARIN C（POM-C）制造，替代了金属部件，因材料重量轻、耐腐蚀。同样因重量轻、耐腐蚀和耐冲击能力卓越，SUSTAMID 6G 也被作为推力喷嘴和 ROV 桶的材料。

水下采油树端帽

在钻探过程中，要在水下采油树安装之前/拆卸之后使用拆卸帽盖住易损的井口。由于这些部件需要使用 ROV 安装，故重量是主要考虑的问题。使用 SUSTARIN C（POM-C）、SUSTAPVDF 和 SUSTAPEEK 等热塑性塑料，重量比传统的金属部件大幅减轻。其他优点还包括：材料天然耐腐蚀、隔热且耐防污液的化学腐蚀。

Rods

Rods made of Sustarin^® C.

水下连接器

由于水下设备越来越复杂，必须使用质量最优的材料加工与生产电气和通信连接器。SustaPEEK^®、SustaPEI^® 和 Sustarin^® C（POM-C）是最佳的解决方案，因其绝缘性良好、吸湿性弱，对干插拔和湿插拔系统尺寸稳定、冲击阻力小。

面包卷的成型圆筒

劳士领材料对于面包卷工业生产中的工艺流程效率贡献很大：采用 SUSTARIN C FG（POM）制成的腔室圆筒沿着与采用制成的成型圆筒相反的方向旋转，从而形成环状面块。

Variants

Show product in Webshop

	SKU	Name	Type	Type	Color	Measurements	Length	Width	Thickness	Height
No stock item (MOQ)	600869	Sustarin® C grey extruded	rod	rod	iron grey, similar RAL 7011	Ø 10 x 3000 mm	3,000 mm		10 mm
No stock item (MOQ)	600905	Sustarin® C grey extruded	sheet	sheet	blue grey, similar RAL 7031	50 x 620 x 1000 mm	1,000 mm	620 mm	50 mm
No stock item (MOQ)	601174	Sustarin® C grey extruded	rod	rod	stone grey, similar RAL 7030	Ø 65 x 3000 mm	3,000 mm		65 mm
No stock item (MOQ)	601948	Sustarin® C grey extruded	sheet	sheet	tarpaulin grey, similar RAL 7010	60 x 620 x 3000 mm	3,000 mm	620 mm	60 mm
No stock item (MOQ)	625221	Sustarin® C grey extruded	tubular bar	tubular bar	light grey, similar RAL 7035	Ø 60/50 x 3000 mm	3,000 mm		60 mm	50 mm
No stock item (MOQ)	634486	Sustarin® C grey extruded	rod	rod	signal grey, similar RAL 7004	Ø 75 x 3000 mm	3,000 mm		75 mm
No stock item (MOQ)	644183	Sustarin® C grey extruded	sheet	sheet	tarpaulin grey, similar RAL 7010	30 x 1000 x 3000 mm	3,000 mm	1,000 mm	30 mm
No stock item (MOQ)	647326	Sustarin® C grey extruded	rod	rod	dust grey, similar RAL 7037	Ø 90 x 3000 mm	3,000 mm		90 mm
No stock item (MOQ)	650748	Sustarin® C grey extruded	rod	rod	window grey, similar RAL 7040	Ø 125 x 3000 mm	3,000 mm		125 mm
No stock item (MOQ)	650749	Sustarin® C grey extruded	rod	rod	window grey, similar RAL 7040	Ø 125 x 1000 mm	1,000 mm		125 mm
No stock item (MOQ)	653916	Sustarin® C grey extruded	sheet	sheet	tarpaulin grey, similar RAL 7010	90 x 620 x 1000 mm	1,000 mm	620 mm	90 mm
No stock item (MOQ)	653917	Sustarin® C grey extruded	sheet	sheet	tarpaulin grey, similar RAL 7010	90 x 620 x 2000 mm	2,000 mm	620 mm	90 mm
No stock item (MOQ)	665503	Sustarin® C grey extruded	sheet	sheet	blue grey, similar RAL 7031	30 x 620 x 2000 mm	2,000 mm	620 mm	30 mm
No stock item (MOQ)	665504	Sustarin® C grey extruded	sheet	sheet	blue grey, similar RAL 7031	45 x 620 x 2000 mm	2,000 mm	620 mm	45 mm
No stock item (MOQ)	692474	Sustarin® C grey extruded	sheet	sheet	light grey, similar RAL 7035	50 x 1000 x 3000 mm	3,000 mm	1,000 mm	50 mm
No stock item (MOQ)	699639	Sustarin® C grey extruded	sheet	sheet	light grey, similar RAL 7035	50 x 1000 x 2000 mm	2,000 mm	1,000 mm	50 mm
No stock item (MOQ)	701806	Sustarin® C grey extruded	rod	rod	window grey, similar RAL 7040	Ø 30 x 3000 mm	3,000 mm		30 mm
No stock item (MOQ)	707901	Sustarin® C grey extruded	sheet	sheet	light grey, similar RAL 7035	50 x 1000 x 1000 mm	1,000 mm	1,000 mm	50 mm
No stock item (MOQ)	715101	Sustarin® C grey extruded	rod	rod	basalt grey, similar RAL 7012	Ø 36 x 3000 mm	3,000 mm		36 mm
No stock item (MOQ)	717449	Sustarin® C grey extruded	rod	rod	light grey, similar RAL 7035	Ø 60 x 3000 mm	3,000 mm		60 mm
No stock item (MOQ)	717839	Sustarin® C grey extruded	rod	rod	window grey, similar RAL 7040	Ø 30 x 1000 mm	1,000 mm		30 mm
No stock item (MOQ)	730422	Sustarin® C grey extruded	rod	rod	signal grey, similar RAL 7004	Ø 90 x 3000 mm	3,000 mm		90 mm
No stock item (MOQ)	733166	Sustarin® C grey extruded	sheet	sheet	dust grey, similar RAL 7037	40 x 620 x 3000 mm	3,000 mm	620 mm	40 mm
No stock item (MOQ)	742511	Sustarin® C grey extruded	rod	rod	dust grey, similar RAL 7037	Ø 25 x 3000 mm	3,000 mm		25 mm
No stock item (MOQ)	742512	Sustarin® C grey extruded	rod	rod	dust grey, similar RAL 7037	Ø 25 x 1000 mm	1,000 mm		25 mm
No stock item (MOQ)	744118	Sustarin® C grey extruded	rod	rod	dust grey, similar RAL 7037	Ø 65 x 3000 mm	3,000 mm		65 mm
No stock item (MOQ)	745548	Sustarin® C grey extruded	sheet	sheet	dust grey, similar RAL 7037	40 x 620 x 1000 mm	1,000 mm	620 mm	40 mm
No stock item (MOQ)	746039	Sustarin® C grey extruded	sheet	sheet	tarpaulin grey, similar RAL 7010	50 x 620 x 2000 mm	2,000 mm	620 mm	50 mm
No stock item (MOQ)	764452	Sustarin® C grey extruded	rod	rod	stone grey, similar RAL 7030	Ø 100 x 3000 mm	3,000 mm		100 mm
No stock item (MOQ)	800880	Sustarin® C grey extruded	rod	rod	light grey, similar RAL 7035	Ø 25 x 3000 mm	3,000 mm		25 mm
No stock item (MOQ)	806137	Sustarin® C grey extruded	rod	rod	window grey, similar RAL 7040	Ø 35 x 3000 mm	3,000 mm		35 mm
No stock item (MOQ)	807010	Sustarin® C grey extruded	rod	rod	dust grey, similar RAL 7037	Ø 75 x 3000 mm	3,000 mm		75 mm
No stock item (MOQ)	807011	Sustarin® C grey extruded	rod	rod	dust grey, similar RAL 7037	Ø 75 x 1000 mm	1,000 mm		75 mm
No stock item (MOQ)	807398	Sustarin® C grey extruded	rod	rod	window grey, similar RAL 7040	Ø 32 x 3000 mm	3,000 mm		32 mm
No stock item (MOQ)	809590	Sustarin® C grey extruded	rod	rod	light grey, similar RAL 7035	Ø 25 x 1000 mm	1,000 mm		25 mm
No stock item (MOQ)	923027	Sustarin® C grey extruded	sheet	sheet	tarpaulin grey, similar RAL 7010	20 x 1000 x 2000 mm	2,000 mm	1,000 mm	20 mm
No stock item (MOQ)	923028	Sustarin® C grey extruded	sheet	sheet	tarpaulin grey, similar RAL 7010	20 x 1000 x 1000 mm	1,000 mm	1,000 mm	20 mm
No stock item (MOQ)	923029	Sustarin® C grey extruded	sheet	sheet	tarpaulin grey, similar RAL 7010	30 x 1000 x 2000 mm	2,000 mm	1,000 mm	30 mm
No stock item (MOQ)	923032	Sustarin® C grey extruded	sheet	sheet	tarpaulin grey, similar RAL 7010	50 x 1000 x 1000 mm	1,000 mm	1,000 mm	50 mm
No stock item (MOQ)	923033	Sustarin® C grey extruded	sheet	sheet	tarpaulin grey, similar RAL 7010	70 x 1000 x 2000 mm	2,000 mm	1,000 mm	70 mm
No stock item (MOQ)	923034	Sustarin® C grey extruded	sheet	sheet	tarpaulin grey, similar RAL 7010	70 x 1000 x 1000 mm	1,000 mm	1,000 mm	70 mm
No stock item (MOQ)	924027	Sustarin® C grey extruded	sheet	sheet	graphite grey, similar RAL 7024	60 x 620 x 1000 mm	1,000 mm	620 mm	60 mm
No stock item (MOQ)	924028	Sustarin® C grey extruded	sheet	sheet	graphite grey, similar RAL 7024	60 x 620 x 3000 mm	3,000 mm	620 mm	60 mm
No stock item (MOQ)	928203	Sustarin® C grey extruded	rod	rod	stone grey, similar RAL 7030	Ø 100 x 1000 mm	1,000 mm		100 mm
No stock item (MOQ)	928345	Sustarin® C grey extruded	rod	rod	khaki grey, similar RAL 7008	Ø 110 x 3000 mm	3,000 mm		110 mm
No stock item (MOQ)	930508	Sustarin® C grey extruded	rod	rod	quartz grey, similar RAL 7039	Ø 60 x 3000 mm	3,000 mm		60 mm
No stock item (MOQ)	930570	Sustarin® C grey extruded	rod	rod	khaki grey, similar RAL 7008	Ø 90 x 3000 mm	3,000 mm		90 mm
No stock item (MOQ)	930571	Sustarin® C grey extruded	rod	rod	khaki grey, similar RAL 7008	Ø 90 x 1000 mm	1,000 mm		90 mm
No stock item (MOQ)	930573	Sustarin® C grey extruded	rod	rod	khaki grey, similar RAL 7008	Ø 70 x 1000 mm	1,000 mm		70 mm
No stock item (MOQ)	930574	Sustarin® C grey extruded	sheet	sheet	khaki grey, similar RAL 7008	50 x 620 x 3000 mm	3,000 mm	620 mm	50 mm
No stock item (MOQ)	930703	Sustarin® C grey extruded	rod	rod	anthracite grey, similar RAL 7016	Ø 40 x 3000 mm	3,000 mm		40 mm
No stock item (MOQ)	931153	Sustarin® C grey extruded	rod	rod	quartz grey, similar RAL 7039	Ø 60 x 1000 mm	1,000 mm		60 mm
No stock item (MOQ)	931359	Sustarin® C grey extruded	sheet	sheet	tarpaulin grey, similar RAL 7010	90 x 1000 x 1000 mm	1,000 mm	1,000 mm	90 mm
No stock item (MOQ)	931826	Sustarin® C grey extruded	sheet	sheet	tarpaulin grey, similar RAL 7010	30 x 1000 x 2500 mm	2,500 mm	1,000 mm	30 mm
No stock item (MOQ)	931958	Sustarin® C grey extruded	rod	rod	khaki grey, similar RAL 7008	Ø 110 x 1000 mm	1,000 mm		110 mm
No stock item (MOQ)	932246	Sustarin® C grey extruded	sheet	sheet	tarpaulin grey, similar RAL 7010	50 x 620 x 1000 mm	1,000 mm	620 mm	50 mm
No stock item (MOQ)	932479	Sustarin® C grey extruded	rod	rod	light grey, similar RAL 7035	Ø 75 x 3000 mm	3,000 mm		75 mm
No stock item (MOQ)	932828	Sustarin® C grey extruded	rod	rod	light grey, similar RAL 7035	Ø 75 x 1000 mm	1,000 mm		75 mm
No stock item (MOQ)	932957	Sustarin® C grey extruded	rod	rod	anthracite grey, similar RAL 7016	Ø 40 x 1000 mm	1,000 mm		40 mm
No stock item (MOQ)	933961	Sustarin® C grey extruded	sheet	sheet	agate grey, similar RAL 7038	30 x 620 x 1000 mm	1,000 mm	620 mm	30 mm
No stock item (MOQ)	934122	Sustarin® C grey extruded	rod	rod	iron grey, similar RAL 7011	Ø 35 x 3000 mm	3,000 mm		35 mm
No stock item (MOQ)	934381	Sustarin® C grey extruded	rod	rod	iron grey, similar RAL 7011	Ø 35 x 1000 mm	1,000 mm		35 mm
No stock item (MOQ)	934778	Sustarin® C grey extruded	sheet	sheet	blue grey, similar RAL 7031	60 x 620 x 2000 mm	2,000 mm	620 mm	60 mm
No stock item (MOQ)	934779	Sustarin® C grey extruded	sheet	sheet	blue grey, similar RAL 7031	50 x 620 x 2000 mm	2,000 mm	620 mm	50 mm
No stock item (MOQ)	934783	Sustarin® C grey extruded	sheet	sheet	blue grey, similar RAL 7031	80 x 620 x 2000 mm	2,000 mm	620 mm	80 mm
No stock item (MOQ)	934812	Sustarin® C grey extruded	sheet	sheet	tarpaulin grey, similar RAL 7010	60 x 620 x 1000 mm	1,000 mm	620 mm	60 mm

Technical Specifications Sustarin® C grey

	Test Method	Unit	Guideline Value
Density	DIN EN ISO 1183-1	g / cm³	1,41
Water absorption	DIN EN ISO 62	%	0,2
Flammability (Thickness 3 mm / 6 mm)	UL 94		HB / HB

	Test Method	Unit	Guideline Value
Yield stress	DIN EN ISO 527	MPa	67
Elongation at break	DIN EN ISO 527	%	30
Tensile modulus of elasticity	DIN EN ISO 527	MPa	2800
Notched impact strength	DIN EN ISO 179	kJ / m²	6
Shore hardness	DIN EN ISO 868	scale D	81

	Test Method	Unit	Guideline Value
Melting temperature	ISO 11357-3	°C	165
Thermal conductivity	DIN 52612-1	W / (m * K)	0,31
Thermal capacity	DIN 52612	kJ / (kg * K)	1,50
Coefficient of linear thermal expansion	DIN 53752	10^-6 / K	110
Service temperature, long term	Average	°C	-50 … 100
Service temperature, short term (max.)	Average	°C	140
Heat deflection temperature	DIN EN ISO 75, Verf. A, HDT	°C	110

	Test Method	Unit	Guideline Value
Dielectric constant	IEC 60250		3,8
Dielectric dissipation factor (50 Hz)	IEC 60250		0,002
Volume resistivity	DIN EN 62631-3-1	Ω * cm	10¹³
Surface resistivity	DIN EN 62631-3-2	Ω	10¹³
Comparative tracking index	IEC 60112		600
Dielectric strength	IEC 60243	kV / mm	40

Downloads

Technical Data Sheet Sustarin® C grey

Product Handling Information Sheet Sustarin® C grey

Flyer - Foils Sustamid Sustarin Sustanat - EN

Flyer - Folien Sustamid Sustarin Sustanat - DE
