Sustarin® C red

POM-C

The construction material for many applications

Sustarin^® C is the brand name for semi-finished products and profiles made from polyacetal copolymer. The special feature of Sustarin^® C is the ideal combination of strength, rigidity, and toughness, which is due to the structure of the product. Due to its high crystallinity, Sustarin^® C is stiffer and stronger than other thermoplastics, especially in the temperature range of -50°C bis +100°C.

raspberry red, similar RAL 3027carmine red, similar RAL 3002traffic red, similar RAL 3020flame red, similar RAL 3000

All colors

rodsheet

Characteristics

Chemical resistant
Low moisture absorption
High abrasion resistance
High tensile strength
High stiffness
Good impact strength
Low creep tendency
Good machinability
Good electrical properties
Good dielectric properties
Good dimensional stability
Good sliding properties

Industries

Application Examples

ROV 部件

遥控潜水器（ROV）不断被用于在越来越深的水域下工作。为助一臂之力，我们提供了很多耐腐蚀的关键部件用来组装 ROV。其中包括本身具有浮力的 Polystone® P（PP）和 Polystone® D（PE-HMW）材料，用以制作侧框架。而电子元件箱则采用 SUSTARIN C（POM-C）制造，替代了金属部件，因材料重量轻、耐腐蚀。同样因重量轻、耐腐蚀和耐冲击能力卓越，SUSTAMID 6G 也被作为推力喷嘴和 ROV 桶的材料。

水下采油树端帽

在钻探过程中，要在水下采油树安装之前/拆卸之后使用拆卸帽盖住易损的井口。由于这些部件需要使用 ROV 安装，故重量是主要考虑的问题。使用 SUSTARIN C（POM-C）、SUSTAPVDF 和 SUSTAPEEK 等热塑性塑料，重量比传统的金属部件大幅减轻。其他优点还包括：材料天然耐腐蚀、隔热且耐防污液的化学腐蚀。

Rods

Rods made of Sustarin^® C.

水下连接器

由于水下设备越来越复杂，必须使用质量最优的材料加工与生产电气和通信连接器。SustaPEEK^®、SustaPEI^® 和 Sustarin^® C（POM-C）是最佳的解决方案，因其绝缘性良好、吸湿性弱，对干插拔和湿插拔系统尺寸稳定、冲击阻力小。

面包卷的成型圆筒

劳士领材料对于面包卷工业生产中的工艺流程效率贡献很大：采用 SUSTARIN C FG（POM）制成的腔室圆筒沿着与采用制成的成型圆筒相反的方向旋转，从而形成环状面块。

Variants

Show product in Webshop

	SKU	Name	Type	Type	Color	Measurements	Length	Width	Thickness
No stock item (MOQ)	141411	Sustarin® C red extruded	rod	rod	raspberry red, similar RAL 3027	Ø 20 x 3000 mm	3,000 mm		20 mm
No stock item (MOQ)	141419	Sustarin® C red extruded	rod	rod	raspberry red, similar RAL 3027	Ø 50 x 3000 mm	3,000 mm		50 mm
No stock item (MOQ)	600872	Sustarin® C red extruded	rod	rod	carmine red, similar RAL 3002	Ø 10 x 3000 mm	3,000 mm		10 mm
No stock item (MOQ)	645998	Sustarin® C red extruded	sheet	sheet	raspberry red, similar RAL 3027	30 x 620 x 2000 mm	2,000 mm	620 mm	30 mm
No stock item (MOQ)	646674	Sustarin® C red extruded	sheet	sheet	raspberry red, similar RAL 3027	40 x 620 x 2000 mm	2,000 mm	620 mm	40 mm
No stock item (MOQ)	651565	Sustarin® C red extruded	sheet	sheet	raspberry red, similar RAL 3027	40 x 620 x 1000 mm	1,000 mm	620 mm	40 mm
No stock item (MOQ)	654653	Sustarin® C red extruded	rod	rod	traffic red, similar RAL 3020	Ø 80 x 3000 mm	3,000 mm		80 mm
No stock item (MOQ)	654659	Sustarin® C red extruded	rod	rod	traffic red, similar RAL 3020	Ø 80 x 1000 mm	1,000 mm		80 mm
No stock item (MOQ)	655730	Sustarin® C red extruded	rod	rod	carmine red, similar RAL 3002	Ø 10 x 1000 mm	1,000 mm		10 mm
No stock item (MOQ)	662286	Sustarin® C red extruded	rod	rod	flame red, similar RAL 3000	Ø 35 x 3000 mm	3,000 mm		35 mm
No stock item (MOQ)	662289	Sustarin® C red extruded	rod	rod	flame red, similar RAL 3000	Ø 35 x 1000 mm	1,000 mm		35 mm
No stock item (MOQ)	678214	Sustarin® C red extruded	sheet	sheet	raspberry red, similar RAL 3027	80 x 1000 x 2000 mm	2,000 mm	1,000 mm	80 mm
No stock item (MOQ)	679409	Sustarin® C red extruded	rod	rod	raspberry red, similar RAL 3027	Ø 40 x 3000 mm	3,000 mm		40 mm
No stock item (MOQ)	679414	Sustarin® C red extruded	rod	rod	raspberry red, similar RAL 3027	Ø 40 x 1000 mm	1,000 mm		40 mm
No stock item (MOQ)	679417	Sustarin® C red extruded	rod	rod	raspberry red, similar RAL 3027	Ø 75 x 3000 mm	3,000 mm		75 mm
No stock item (MOQ)	679425	Sustarin® C red extruded	rod	rod	raspberry red, similar RAL 3027	Ø 75 x 1000 mm	1,000 mm		75 mm
No stock item (MOQ)	680530	Sustarin® C red extruded	rod	rod	orient red, similar RAL 3031	Ø 20 x 3000 mm	3,000 mm		20 mm
No stock item (MOQ)	683784	Sustarin® C red extruded	rod	rod	ruby red, similar RAL 3003	Ø 100 x 3000 mm	3,000 mm		100 mm
No stock item (MOQ)	683786	Sustarin® C red extruded	rod	rod	ruby red, similar RAL 3003	Ø 125 x 3000 mm	3,000 mm		125 mm
No stock item (MOQ)	683787	Sustarin® C red extruded	rod	rod	ruby red, similar RAL 3003	Ø 150 x 3000 mm	3,000 mm		150 mm
No stock item (MOQ)	683788	Sustarin® C red extruded	rod	rod	ruby red, similar RAL 3003	Ø 180 x 3000 mm	3,000 mm		180 mm
No stock item (MOQ)	683791	Sustarin® C red extruded	rod	rod	ruby red, similar RAL 3003	Ø 200 x 3000 mm	3,000 mm		200 mm
No stock item (MOQ)	686574	Sustarin® C red extruded	rod	rod	traffic red, similar RAL 3020	Ø 60 x 3000 mm	3,000 mm		60 mm
No stock item (MOQ)	693609	Sustarin® C red extruded	sheet	sheet	raspberry red, similar RAL 3027	50 x 620 x 3000 mm	3,000 mm	620 mm	50 mm
No stock item (MOQ)	695526	Sustarin® C red extruded	rod	rod	ruby red, similar RAL 3003	Ø 180 x 1000 mm	1,000 mm		180 mm
No stock item (MOQ)	695948	Sustarin® C red extruded	rod	rod	ruby red, similar RAL 3003	Ø 200 x 1000 mm	1,000 mm		200 mm
No stock item (MOQ)	699333	Sustarin® C red extruded	rod	rod	traffic red, similar RAL 3020	Ø 60 x 1000 mm	1,000 mm		60 mm
No stock item (MOQ)	704833	Sustarin® C red extruded	sheet	sheet	raspberry red, similar RAL 3027	50 x 620 x 1000 mm	1,000 mm	620 mm	50 mm
No stock item (MOQ)	718101	Sustarin® C red extruded	rod	rod	ruby red, similar RAL 3003	Ø 100 x 1000 mm	1,000 mm		100 mm
No stock item (MOQ)	722607	Sustarin® C red extruded	sheet	sheet	raspberry red, similar RAL 3027	70 x 1000 x 2000 mm	2,000 mm	1,000 mm	70 mm
No stock item (MOQ)	739655	Sustarin® C red extruded	sheet	sheet	raspberry red, similar RAL 3027	70 x 1000 x 1000 mm	1,000 mm	1,000 mm	70 mm
No stock item (MOQ)	739727	Sustarin® C red extruded	sheet	sheet	raspberry red, similar RAL 3027	40 x 1000 x 2000 mm	2,000 mm	1,000 mm	40 mm
No stock item (MOQ)	741064	Sustarin® C red extruded	sheet	sheet	raspberry red, similar RAL 3027	80 x 1000 x 1000 mm	1,000 mm	1,000 mm	80 mm
No stock item (MOQ)	746959	Sustarin® C red extruded	sheet	sheet	raspberry red, similar RAL 3027	40 x 1000 x 1000 mm	1,000 mm	1,000 mm	40 mm
No stock item (MOQ)	756473	Sustarin® C red extruded	rod	rod	traffic red, similar RAL 3020	Ø 75 x 3000 mm	3,000 mm		75 mm
No stock item (MOQ)	758908	Sustarin® C red extruded	rod	rod	traffic red, similar RAL 3020	Ø 75 x 1000 mm	1,000 mm		75 mm
No stock item (MOQ)	803941	Sustarin® C red extruded	rod	rod	raspberry red, similar RAL 3027	Ø 20 x 1000 mm	1,000 mm		20 mm
No stock item (MOQ)	803945	Sustarin® C red extruded	rod	rod	raspberry red, similar RAL 3027	Ø 50 x 1000 mm	1,000 mm		50 mm
No stock item (MOQ)	803946	Sustarin® C red extruded	rod	rod	raspberry red, similar RAL 3027	Ø 60 x 1000 mm	1,000 mm		60 mm
No stock item (MOQ)	804499	Sustarin® C red extruded	sheet	sheet	raspberry red, similar RAL 3027	80 x 620 x 2000 mm	2,000 mm	620 mm	80 mm
No stock item (MOQ)	809860	Sustarin® C red extruded	rod	rod	traffic red, similar RAL 3020	Ø 50 x 3000 mm	3,000 mm		50 mm
No stock item (MOQ)	925412	Sustarin® C red extruded	sheet	sheet	raspberry red, similar RAL 3027	20 x 620 x 3000 mm	3,000 mm	620 mm	20 mm
No stock item (MOQ)	925413	Sustarin® C red extruded	sheet	sheet	raspberry red, similar RAL 3027	25 x 620 x 1000 mm	1,000 mm	620 mm	25 mm
No stock item (MOQ)	925414	Sustarin® C red extruded	sheet	sheet	raspberry red, similar RAL 3027	25 x 620 x 3000 mm	3,000 mm	620 mm	25 mm
No stock item (MOQ)	925434	Sustarin® C red extruded	rod	rod	raspberry red, similar RAL 3027	Ø 20 x 3000 mm	3,000 mm		20 mm
No stock item (MOQ)	925437	Sustarin® C red extruded	rod	rod	raspberry red, similar RAL 3027	Ø 30 x 1000 mm	1,000 mm		30 mm
No stock item (MOQ)	925438	Sustarin® C red extruded	rod	rod	raspberry red, similar RAL 3027	Ø 30 x 3000 mm	3,000 mm		30 mm
No stock item (MOQ)	925443	Sustarin® C red extruded	rod	rod	raspberry red, similar RAL 3027	Ø 50 x 1000 mm	1,000 mm		50 mm
No stock item (MOQ)	925444	Sustarin® C red extruded	rod	rod	raspberry red, similar RAL 3027	Ø 50 x 3000 mm	3,000 mm		50 mm
No stock item (MOQ)	925445	Sustarin® C red extruded	rod	rod	raspberry red, similar RAL 3027	Ø 60 x 1000 mm	1,000 mm		60 mm
No stock item (MOQ)	925446	Sustarin® C red extruded	rod	rod	raspberry red, similar RAL 3027	Ø 60 x 3000 mm	3,000 mm		60 mm
No stock item (MOQ)	925449	Sustarin® C red extruded	rod	rod	raspberry red, similar RAL 3027	Ø 80 x 1000 mm	1,000 mm		80 mm
No stock item (MOQ)	925450	Sustarin® C red extruded	rod	rod	raspberry red, similar RAL 3027	Ø 80 x 3000 mm	3,000 mm		80 mm
No stock item (MOQ)	925451	Sustarin® C red extruded	rod	rod	raspberry red, similar RAL 3027	Ø 45 x 1000 mm	1,000 mm		45 mm
No stock item (MOQ)	925452	Sustarin® C red extruded	rod	rod	raspberry red, similar RAL 3027	Ø 45 x 3000 mm	3,000 mm		45 mm
No stock item (MOQ)	925695	Sustarin® C red extruded	rod	rod	raspberry red, similar RAL 3027	Ø 6 x 3000 mm	3,000 mm		6 mm
No stock item (MOQ)	933779	Sustarin® C red extruded	rod	rod	raspberry red, similar RAL 3027	Ø 10 x 3000 mm	3,000 mm		10 mm
No stock item (MOQ)	933968	Sustarin® C red extruded	sheet	sheet	raspberry red, similar RAL 3027	80 x 620 x 1000 mm	1,000 mm	620 mm	80 mm
No stock item (MOQ)	934692	Sustarin® C red extruded	rod	rod	traffic red, similar RAL 3020	Ø 25 x 3000 mm	3,000 mm		25 mm

Technical Specifications Sustarin® C red

General properties

	Test Method	Unit	Guideline Value
Density	DIN EN ISO 1183-1	g / cm³	1,41
Water absorption	DIN EN ISO 62	%	0,2
Flammability (Thickness 3 mm / 6 mm)	UL 94		HB / HB

Mechanical properties

	Test Method	Unit	Guideline Value
Yield stress	DIN EN ISO 527	MPa	67
Elongation at break	DIN EN ISO 527	%	30
Tensile modulus of elasticity	DIN EN ISO 527	MPa	2800
Notched impact strength	DIN EN ISO 179	kJ / m²	6
Shore hardness	DIN EN ISO 868	scale D	81

Thermal properties

	Test Method	Unit	Guideline Value
Melting temperature	ISO 11357-3	°C	165
Thermal conductivity	DIN 52612-1	W / (m * K)	0,31
Thermal capacity	DIN 52612	kJ / (kg * K)	1,50
Coefficient of linear thermal expansion	DIN 53752	10^-6 / K	110
Service temperature, long term	Average	°C	-50 … 100
Service temperature, short term (max.)	Average	°C	140
Heat deflection temperature	DIN EN ISO 75, Verf. A, HDT	°C	110

Electrical properties

	Test Method	Unit	Guideline Value
Dielectric constant	IEC 60250		3,8
Dielectric dissipation factor (50 Hz)	IEC 60250		0,002
Volume resistivity	DIN EN 62631-3-1	Ω * cm	10¹³
Surface resistivity	DIN EN 62631-3-2	Ω	10¹³
Comparative tracking index	IEC 60112		600
Dielectric strength	IEC 60243	kV / mm	40
