Variants
| SKU | Name | Type | Type | Color | Measurements | Length | Width | Thickness | Height | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| No stock item (MOQ) | 886137 | SustaPEEK CM ESD 60 black pressed | sheet | sheet | black | 16 x 395 x 395 mm | 395 mm | 395 mm | 16 mm |
Technical Specifications SustaPEEK CM ESD 60 black
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Density | DIN EN ISO 1183-1 | g / cm3 | 1,47 |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Elongation at break | DIN EN ISO 527 | % | 1 |
| Tensile strength | DIN EN ISO 527 | MPa | 50 |
| Impact strength | DIN EN ISO 179 | kJ / m2 | 6 |
| Notched impact strength | ISO 179-1/1eA | kJ / m2 | 2 |
| Shore hardness | DIN EN ISO 868 | scale D | 82 |
| Ball indentation hardness | DIN EN ISO 2039-1 | MPa | 231 |
| Elastic modulus of compression | DIN EN ISO 604 | MPa | 3800 |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Melting temperature | ISO 11357-3 | °C | 342 |
| Service temperature, long term | Average | °C | -60...250 |
| Service temperature, short term (max.) | Average | °C | 300 |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Surface resistivity | DIN EN 62631-3-2 | Ω | =104 |
