SustaPEI GF 30 natural
PEI
The Reinforced Amorphous High Performance Polymer
The addition of 30 % glass fibre by weight increases the mechanical strength and rigidity compared to unfilled PEI across the entire application temperature range to an even higher level. At the same time, the thermal expansion coefficient is lower. SustaPEI GF30 is therefore particularly suitable for components that are subject to high mechanical loads and require high dimensional stability. Application temperatures of up to ap 170°C continuously and 190°C for short periods are possible.
natural
rod
Characteristics
- High heat deflection temperature
- Flame retardant
- Low smoke development
- High stiffness
- High tensile strength
- High hardness
- high dimensional stability under heat
Industries
Variants
| SKU | Name | Type | Type | Color | Measurements | Length | Width | Thickness | Height | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| No stock item (MOQ) | 696851 | SustaPEI GF 30 natural extruded | rod | rod | natural | Ø 80 x 3000 mm | 3,000 mm | 80 mm | |||
| No stock item (MOQ) | 697173 | SustaPEI GF 30 natural extruded | rod | rod | natural | Ø 80 x 1000 mm | 1,000 mm | 80 mm | |||
| No stock item (MOQ) | 700289 | SustaPEI GF 30 natural extruded | rod | rod | natural | Ø 110 x 1000 mm | 1,000 mm | 110 mm |
Technical Specifications SustaPEI GF 30 natural
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Density | DIN EN ISO 1183-1 | g / cm3 | 1,51 |
| Water absorption | DIN EN ISO 62 | % | 0,4 |
| Flammability (Thickness 3 mm / 6 mm) | UL 94 | V0 / V0 |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Yield stress | DIN EN ISO 527 | MPa | 120 |
| Elongation at break | DIN EN ISO 527 | % | 4 |
| Tensile modulus of elasticity | DIN EN ISO 527 | MPa | 5000 |
| Shore hardness | DIN EN ISO 868 | scale D | 92 |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Melting temperature | ISO 11357-3 | °C | - |
| Glass transition temperature | ISO 11357-3 | °C | 217 |
| Service temperature, long term | Average | °C | -30 … 170 |
| Service temperature, short term (max.) | Average | °C | 210 |
| Heat deflection temperature | DIN EN ISO 75, Verf. A, HDT | °C | 210 |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Dielectric constant | IEC 60250 | 3,3 | |
| Dielectric dissipation factor (50 Hz) | IEC 60250 | 0,0016 | |
| Volume resistivity | DIN EN 62631-3-1 | Ω * cm | 1015 |
| Surface resistivity | DIN EN 62631-3-2 | Ω | 1015 |
| Comparative tracking index | IEC 60112 | 150 | |
| Dielectric strength | IEC 60243 | kV / mm | 35 |
