EtroX® I CM G15 grey
PI
anthracite
sheet
Characteristics
- high dimensional stability under heat
- Heat resistant
- Low creep tendency
- Low moisture absorption
Industries
Variants
| SKU | Name | Type | Type | Color | Measurements | Length | Width | Thickness | Height | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| No stock item (MOQ) | 761042 | EtroX® I CM G15 grey pressed | sheet | sheet | anthracite | 16 x 395 x 395 mm | 395 mm | 395 mm | 16 mm | ||
| No stock item (MOQ) | 772247 | EtroX® I CM G15 grey pressed | sheet | sheet | anthracite | 20 x 395 x 395 mm | 395 mm | 395 mm | 20 mm |
Technical Specifications EtroX® I CM G15 grey
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Density | DIN EN ISO 1183-1 | g / cm3 | 1,46 |
| Water absorption | DIN EN ISO 62 (23°C / 24h) | % | 0,6 |
| Water absorption | DIN EN ISO 62 (23°C / 48h) | % | 0,8 |
| Water absorption | DIN EN ISO 62 (23°C / 3 Weeks) | % | 2,1 |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Elongation at break | DIN EN ISO 527 | % | 5 |
| Tensile modulus of elasticity | DIN EN ISO 527 | MPa | 3900 |
| Tensile strength | DIN EN ISO 527 | MPa | 100 |
| Impact strength | DIN EN ISO 179 | kJ / m2 | 40 |
| Notched impact strength | DIN EN ISO 179 | kJ / m2 | 3 |
| Shore hardness | DIN EN ISO 868 | scale D | 85 |
| Elastic modulus of compression | DIN EN ISO 604 | MPa | 2700 |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Temp. of deflection under load, 1.80 MPa | ISO 75-1/-2 | °C | 335 |
| Temp. of deflection under load, 0.45 MPa | ISO 75-1/-2 | °C | 345 |
