Variants
| SKU | Name | Type | Type | Color | Measurements | Length | Width | Thickness | Height | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| No stock item (MOQ) | 657510 | Sustatron® PPS black extruded | sheet | sheet | black | 25 x 620 x 1000 mm | 1,000 mm | 620 mm | 25 mm | ||
| No stock item (MOQ) | 657511 | Sustatron® PPS black extruded | sheet | sheet | black | 25 x 620 x 3000 mm | 3,000 mm | 620 mm | 25 mm | ||
| No stock item (MOQ) | 929721 | Sustatron® PPS black extruded | sheet | sheet | black | 16 x 620 x 1000 mm | 1,000 mm | 620 mm | 16 mm |
Technical Specifications Sustatron® PPS black
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Density | DIN EN ISO 1183-1 | g / cm3 | 1,35 |
| Water absorption | DIN EN ISO 62 | % | 0,0 |
| Flammability (Thickness 3 mm / 6 mm) | UL 94 | V0 / V0 |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Yield stress | DIN EN ISO 527 | MPa | 90 |
| Elongation at break | DIN EN ISO 527 | % | 3 |
| Tensile modulus of elasticity | DIN EN ISO 527 | MPa | 4150 |
| Shore hardness | DIN EN ISO 868 | scale D | 88 |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Melting temperature | ISO 11357-3 | °C | 285 |
| Service temperature, long term | Average | °C | -20 … 220 |
| Service temperature, short term (max.) | Average | °C | 260 |
| Heat deflection temperature | DIN EN ISO 75, Verf. A, HDT | °C | 110 |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Volume resistivity | DIN EN 62631-3-1 | Ω * cm | 1013 |
| Surface resistivity | DIN EN 62631-3-2 | Ω | 1015 |
