Variants
| SKU | Name | Type | Type | Color | Measurements | Length | Width | Thickness | Height | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| Stock item (no MOQ) | 100330 | Durostone® EPC 308 pressed | sheet | sheet | 3.030 x 1.220 x 5 (+/-0,52) mm | 3,030 mm | 1,220 mm | 5 mm | |||
| Stock item (no MOQ) | 100331 | Durostone® EPC 308 pressed | sheet | sheet | 3.030 x 1.220 x 6 (+/-0,6) mm | 3,030 mm | 1,220 mm | 6 mm | |||
| No stock item (MOQ) | 100333 | Durostone® EPC 308 pressed | sheet | sheet | 3.030 x 1.220 x 10 (+/-0,82) mm | 3,030 mm | 1,220 mm | 10 mm | |||
| No stock item (MOQ) | 100334 | Durostone® EPC 308 pressed | sheet | sheet | 3.030 x 1.220 x 12 (+/-0,94) mm | 3,030 mm | 1,220 mm | 12 mm | |||
| Stock item (no MOQ) | 100335 | Durostone® EPC 308 pressed | sheet | sheet | 3.030 x 1.220 x 15 (+/-1,12) mm | 3,030 mm | 1,220 mm | 15 mm | |||
| Stock item (no MOQ) | 100337 | Durostone® EPC 308 pressed | sheet | sheet | 3.030 x 1.220 x 20 (+/-1,3) mm | 3,030 mm | 1,220 mm | 20 mm | |||
| Stock item (no MOQ) | 101485 | Durostone® EPC 308 pressed | sheet | sheet | 3.030 x 1.220 x 22 (+/-1,5) mm | 3,030 mm | 1,220 mm | 22 mm | |||
| Stock item (no MOQ) | 101486 | Durostone® EPC 308 pressed | sheet | sheet | 3.030 x 1.220 x 25 (+/-1,5) mm | 3,030 mm | 1,220 mm | 25 mm | |||
| No stock item (MOQ) | 234197 | Durostone® EPC 308 pressed | sheet | sheet | 3.030 x 1.220 x 14 (+/-1) mm | 3,030 mm | 1,220 mm | 14 mm | |||
| No stock item (MOQ) | 255173 | Durostone® EPC 308 pressed | sheet | sheet | 3.030 x 1.220 x 30 (+/-1,95) mm | 3,030 mm | 1,220 mm | 30 mm | |||
| Stock item (no MOQ) | 270085 | Durostone® EPC 308 pressed | sheet | sheet | 3.030 x 1.220 x 2,5 (+/-0,33) mm | 3,030 mm | 1,220 mm | 2.5 mm | |||
| Stock item (no MOQ) | 340224 | Durostone® EPC 308 pressed | sheet | sheet | 3.030 x 1.220 x 28 (+/-1,8) mm | 3,030 mm | 1,220 mm | 28 mm | |||
| Stock item (no MOQ) | 467821 | Durostone® EPC 308 pressed | sheet | sheet | 3.030 x 1.220 x 27 (+/-1,7) mm | 3,030 mm | 1,220 mm | 27 mm |
Technical Specifications Durostone® EPC 308
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Density | ISO 1183 | g / cm3 | 1,85 |
| Flexural strength ┴ | ISO 178 | MPa | 450 |
| Flexural strength ┴ +150°C | ISO 178 | MPa | 230 |
| Modulus of elasticity in flexion ┴ | ISO 178 | MPa | 23000 |
| Modulus of elasticity in flexion ┴ +150°C | ISO 178 | MPa | 18000 |
| Compressive strength ┴ | ISO 604 | MPa | 500 |
| Tensile strength II | ISO 527 | MPa | 400 |
| Impact strength II (Charpy) | ISO 179 | kJ / m2 | 100 |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Temperature index | IEC 60216 | T.I. | 180 |
| Insulation class | IEC 60085 | / | H |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Water absorption (4mm thickness) | ISO 62 | % | 0,1 |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Electric strength 90°C under oil ┴ | IEC 60243 | kV / mm | 16 |
| Electric strength 90°C under oil II | IEC 60243 | kV/25mm | 80 |
| Specific surface resistance | IEC 60093 | Ω | 5 x 1010 |
| Comparative tracking index | IEC 60112 | CTI | 180 |
