Variants
| SKU | Name | Type | Type | Color | Measurements | Length | Width | Thickness | Height | ||
|---|---|---|---|---|---|---|---|---|---|---|---|
| No stock item (MOQ) | 111184 | Sustamid® 6 GF 30 black extruded | rod | rod | black | Ø 20 x 3000 mm | 3,000 mm | 20 mm | |||
| No stock item (MOQ) | 111187 | Sustamid® 6 GF 30 black extruded | rod | rod | black | Ø 30 x 3000 mm | 3,000 mm | 30 mm | |||
| No stock item (MOQ) | 111189 | Sustamid® 6 GF 30 black extruded | rod | rod | black | Ø 40 x 3000 mm | 3,000 mm | 40 mm | |||
| No stock item (MOQ) | 111190 | Sustamid® 6 GF 30 black extruded | rod | rod | black | Ø 45 x 3000 mm | 3,000 mm | 45 mm | |||
| No stock item (MOQ) | 111191 | Sustamid® 6 GF 30 black extruded | rod | rod | black | Ø 50 x 3000 mm | 3,000 mm | 50 mm | |||
| No stock item (MOQ) | 111192 | Sustamid® 6 GF 30 black extruded | rod | rod | black | Ø 60 x 3000 mm | 3,000 mm | 60 mm | |||
| No stock item (MOQ) | 111193 | Sustamid® 6 GF 30 black extruded | rod | rod | black | Ø 70 x 3000 mm | 3,000 mm | 70 mm | |||
| No stock item (MOQ) | 111194 | Sustamid® 6 GF 30 black extruded | rod | rod | black | Ø 80 x 3000 mm | 3,000 mm | 80 mm | |||
| No stock item (MOQ) | 111196 | Sustamid® 6 GF 30 black extruded | rod | rod | black | Ø 100 x 3000 mm | 3,000 mm | 100 mm | |||
| No stock item (MOQ) | 111201 | Sustamid® 6 GF 30 black extruded | rod | rod | black | Ø 100 x 1000 mm | 1,000 mm | 100 mm | |||
| No stock item (MOQ) | 803495 | Sustamid® 6 GF 30 black extruded | rod | rod | black | Ø 80 x 1000 mm | 1,000 mm | 80 mm | |||
| No stock item (MOQ) | 803583 | Sustamid® 6 GF 30 black extruded | rod | rod | black | Ø 60 x 1000 mm | 1,000 mm | 60 mm | |||
| No stock item (MOQ) | 804055 | Sustamid® 6 GF 30 black extruded | rod | rod | black | Ø 30 x 1000 mm | 1,000 mm | 30 mm | |||
| No stock item (MOQ) | 804056 | Sustamid® 6 GF 30 black extruded | rod | rod | black | Ø 40 x 1000 mm | 1,000 mm | 40 mm | |||
| No stock item (MOQ) | 804058 | Sustamid® 6 GF 30 black extruded | rod | rod | black | Ø 50 x 1000 mm | 1,000 mm | 50 mm | |||
| No stock item (MOQ) | 804352 | Sustamid® 6 GF 30 black extruded | rod | rod | black | Ø 70 x 1000 mm | 1,000 mm | 70 mm | |||
| No stock item (MOQ) | 921613 | Sustamid® 6 GF 30 black extruded | rod | rod | black | Ø 20 x 1000 mm | 1,000 mm | 20 mm |
Technical Specifications Sustamid® 6 GF 30 black
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Density | DIN EN ISO 1183-1 | g / cm3 | 1,35 |
| Water absorption | DIN EN ISO 62 | % | 2,0 |
| Flammability (Thickness 3 mm / 6 mm) | UL 94 | HB / HB |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Yield stress | DIN EN ISO 527 | MPa | 85 |
| Elongation at break | DIN EN ISO 527 | % | 5 |
| Tensile modulus of elasticity | DIN EN ISO 527 | MPa | 4500 |
| Notched impact strength | DIN EN ISO 179 | kJ / m2 | 4 |
| Shore hardness | DIN EN ISO 868 | scale D | 86 |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Melting temperature | ISO 11357-3 | °C | 220 |
| Thermal conductivity | DIN 52612-1 | W / (m * K) | 0,28 |
| Thermal capacity | DIN 52612 | kJ / (kg * K) | 1,50 |
| Coefficient of linear thermal expansion | DIN 53752 | 10-6 / K | 60 |
| Service temperature, long term | Average | °C | -30 … 110 |
| Service temperature, short term (max.) | Average | °C | 180 |
| Heat deflection temperature | DIN EN ISO 75, Verf. A, HDT | °C | 140 |
