LubX® AST black

PE — PE-UHMW - PE 1000

black, similar RAL 9005

profilesheet

Characteristics

Antistatic
Good dry-running properties
Good wear resistance
Good sliding properties

Industries

机械工程行业
输送机技术和自动化
食品行业
烘焙店和糖果店
饮料行业

Application Examples

用于输送机系统的滑动组件

我们的 LubX^® 产品系列提供专为输送机技术开发的高性能滑动材料。配备有 LubX^® 的输送机系统因其滑动性能出色，所需能量减少，避免了粘滑效应，提高了工艺稳定性。根据具体应用，我们推荐 LubX^® CV、 LubX^® C、 LubX^® S 或 LubX^®Ast black

螺旋速冻机的滑轨

我们 LubX^® 材料制作的型材用在制作速冻披萨的螺旋速冻机的结构中。由于具有出色的滑动性能，此材料可以降低所需的传动力以及所用的能源。LubX^® 满足法规 10/2011/EU 和 FDA 的要求，适合直接接触食品。根据具体应用，我们推荐 LubX^® CV、 LubX^® C、 LubX^® S 或 LubX^® Ast black

饮料装瓶设备的滑动组件

我们的 LubX^® 产品系列提供专为输送机技术开发的重载荷滑动材料。由于具有出色的滑动特性，配备了 LubX^® 的输送机系统（例如，饮料装瓶设备中的输送机系统）只需较少的能耗、避免了滑动粘附效应以及改进了输送机工艺流程的稳定性。根据具体应用，我们推荐 LubX^® CV、 LubX^® C、 LubX^® S 或 LubX^® Ast black。

Variants

	SKU	Name	Type	Type	Color	Measurements	Length	Width	Thickness
No stock item (MOQ)	373451	LubX® AST black extruded	Special profile	Special profile (R593)	black, similar RAL 9005	30.000 x 11,5 x 12 mm	30,000 mm	11.5 mm	12 mm
No stock item (MOQ)	418756	LubX® AST black extruded	Special profile	Special profile (R699)	black, similar RAL 9005	6.020 (-0/+30) x 18,4 x 6 mm	6,020 mm	18.4 mm	6 mm
No stock item (MOQ)	460446	LubX® AST black extruded	Special profile	Special profile (R779)	black, similar RAL 9005	3000 (-0/+30) x 17 x 6,2 mm	3,000 mm	17 mm	6.2 mm
No stock item (MOQ)	471221	LubX® AST black extruded	Special profile	Special profile (R779)	black, similar RAL 9005	6000 (-0/+20) x 17 x 6,2 mm	6,000 mm	17 mm	6.2 mm
No stock item (MOQ)	510729	LubX® AST black extruded	Clamp profile	Clamp profile (R745)	black, similar RAL 9005	25.000 x 10,2 x 6,2 mm	25,000 mm	10.2 mm	6.2 mm
No stock item (MOQ)	510731	LubX® AST black extruded	Special profile	Special profile	black, similar RAL 9005	4.000 (-0/+50) x 25,09 x 5,5 mm	4,000 mm	25.09 mm	5.5 mm
No stock item (MOQ)	380271	LubX® AST black pressed	sheet	sheet	black, similar RAL 9005	15 x 1000 x 2000 mm	2,000 mm	1,000 mm	15 mm
No stock item (MOQ)	401972	LubX® AST black pressed	sheet	sheet	black, similar RAL 9005	50 x 1000 x 2000 mm	2,000 mm	1,000 mm	50 mm
No stock item (MOQ)	443420	LubX® AST black pressed	sheet	sheet	black, similar RAL 9005	20 x 1000 x 2000 mm	2,000 mm	1,000 mm	20 mm
No stock item (MOQ)	443440	LubX® AST black pressed	sheet	sheet	black, similar RAL 9005	20 x 2000 x 6000 mm	6,000 mm	2,000 mm	20 mm
No stock item (MOQ)	450813	LubX® AST black pressed	sheet	sheet	black, similar RAL 9005	25 x 2000 x 6000 mm	6,000 mm	2,000 mm	25 mm

Technical Specifications LubX® AST black extruded

	Test Method	Unit	Guideline Value
Density	DIN EN ISO 1183-1	g / cm³	0,94
Water absorption	DIN EN ISO 62	%	0,01
Flammability (Thickness 3 mm / 6 mm)	UL 94		HB

	Test Method	Unit	Guideline Value
Yield stress	DIN EN ISO 527	MPa	20
Elongation at break	DIN EN ISO 527	%	>50
Tensile modulus of elasticity	DIN EN ISO 527	MPa	650
Notched impact strength	DIN EN ISO 179	kJ / m²	no break
Shore hardness	DIN EN ISO 868	scale D	60

	Test Method	Unit	Guideline Value
Melting temperature	ISO 11357-3	°C	133 – 135
Coefficient of linear thermal expansion	DIN 53752	10^-6 / K	150 - 230 (*)
Service temperature, long term	Average	°C	-150 … 80 (*)
Service temperature, short term (max.)	Average	°C	130 (*)

	Test Method	Unit	Guideline Value
Surface resistivity	DIN EN 62631-3-2	Ω	10⁹

Technical Specifications LubX® AST black pressed

	Test Method	Unit	Guideline Value
Density	DIN EN ISO 1183-1	g / cm³	0,94
Water absorption	DIN EN ISO 62	%	0,01
Flammability (Thickness 3 mm / 6 mm)	UL 94		HB

	Test Method	Unit	Guideline Value
Yield stress	DIN EN ISO 527	MPa	20
Elongation at break	DIN EN ISO 527	%	>50
Tensile modulus of elasticity	DIN EN ISO 527	MPa	650
Notched impact strength	DIN EN ISO 179	kJ / m²	no break
Shore hardness	DIN EN ISO 868	scale D	60

	Test Method	Unit	Guideline Value
Melting temperature	ISO 11357-3	°C	133 – 135
Coefficient of linear thermal expansion	DIN 53752	10^-6 / K	150 - 230 (*)
Service temperature, long term	Average	°C	-150 … 80 (*)
Service temperature, short term (max.)	Average	°C	130 (*)

	Test Method	Unit	Guideline Value
Surface resistivity	DIN EN 62631-3-2	Ω	10⁹

Downloads

Technical Data Sheet LubX® AST black extruded

Technical Data Sheet LubX® AST black pressed

Product Handling Information Sheet LubX® AST black pressed

EC Compliance LubX® AST black pressed
