Technical Specifications Formaterm® PS-HI sign-advertising
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Density | DIN EN ISO 1183-1 | g / cm3 | 1,04 |
| Water absorption | DIN EN ISO 62 | % | 0,2 – 0,3 |
| Flammability (Thickness 3 mm / 6 mm) | UL 94 | HB |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Yield stress | DIN EN ISO 527 | MPa | 21 |
| Elongation at break | DIN EN ISO 527 | % | 60 |
| Tensile modulus of elasticity | DIN EN ISO 527 | MPa | 1850 |
| Notched impact strength | DIN EN ISO 179 | kJ / m2 | 10 |
| Shore hardness | DIN EN ISO 868 | scale D | 80 |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Glass transition temperature | ISO 11357-3 | °C | 95 – 100 |
| Thermal conductivity | DIN 52612-1 | W / (m * K) | 0,18 |
| Coefficient of linear thermal expansion | DIN 53752 | 10-6 / K | 70 |
| Service temperature, long term | Average | °C | -10 … 80 |
| Service temperature, short term (max.) | Average | °C | 75 – 90 |
| Vicat softening temperature | DIN EN ISO 306, Vicat B | °C | 99 |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Dielectric constant | IEC 60250 | 2,50 | |
| Dielectric dissipation factor (106 Hz) | IEC 60250 | 0,0004 | |
| Volume resistivity | DIN EN 62631-3-1 | Ω * cm | >1016 |
| Surface resistivity | DIN EN 62631-3-2 | Ω | >1015 |
| Dielectric strength | IEC 60243 | kV / mm | 40 |
