Technical Specifications Fibracon® PTFE CLF
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Specific Gravity | ASTM D4894 | - | 2.09 |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Hardness | Needle | Shore D | 62 |
| Tensile Strength (Cross Direction) | ASTM D4894 | MPa | 28 |
| Elongation | ASTM D4894 | % | 320 |
| Deformation under load | 13.7MPa, 23°C 24h | % | 8.2 |
| Wear factor | Thrust type / ring on ring P=0.45 MPa, V=1.0 m/s Counter material: Al | 10-7 mm3 / (Nm) | 18 |
| Coefficient of friction | Thrust type / ring on ring P=0.45 MPa, V=1.0 m/s Counter material: Al | - | 0.15 |
| Test Method | Unit | Guideline Value | |
|---|---|---|---|
| Service Temperature | °C | -200 to +260 |
