Polystone® PPs EL black

PP-H

black, similar RAL 9005

sheetwelding rod

Characteristics

Flame retardant
Antistatic
Electrically conductive

Industries

Variants

Show product in Webshop

	SKU	Name	Type	Type	Color	Measurements	Length	Width	Thickness
Stock item (no MOQ)	100638	Polystone® PPs EL black extruded	sheet	sheet	black, similar RAL 9005	4 x 1500 x 3000 mm	3,000 mm	1,500 mm	4 mm
Stock item (no MOQ)	100639	Polystone® PPs EL black extruded	sheet	sheet	black, similar RAL 9005	8 x 1500 x 3000 mm	3,000 mm	1,500 mm	8 mm
Stock item (no MOQ)	100640	Polystone® PPs EL black extruded	sheet	sheet	black, similar RAL 9005	10 x 1500 x 3000 mm	3,000 mm	1,500 mm	10 mm
Stock item (no MOQ)	100648	Polystone® PPs EL black extruded	sheet	sheet	black, similar RAL 9005	6 x 1500 x 3000 mm	3,000 mm	1,500 mm	6 mm
No stock item (MOQ)	218646	Polystone® PPs EL black extruded	welding rod	welding rod	black, similar RAL 9005	Ø 3 (+/-0,2) mm			3 mm
Stock item (no MOQ)	218647	Polystone® PPs EL black extruded	welding rod	welding rod	black, similar RAL 9005	Ø 4 (-0,3/+0,2) mm			4 mm
Stock item (no MOQ)	230254	Polystone® PPs EL black extruded	sheet	sheet	black, similar RAL 9005	5 x 1500 x 3000 mm	3,000 mm	1,500 mm	5 mm
Stock item (no MOQ)	246430	Polystone® PPs EL black extruded	welding rod	welding rod	black, similar RAL 9005	2.000 x 6 (+/-0,3) x 4,5 (-0,4/+0) mm	2,000 mm	6 mm	4.5 mm
No stock item (MOQ)	272660	Polystone® PPs EL black extruded	welding rod	welding rod	black, similar RAL 9005	B=6 (+/-0,3) x 4,5 (-0,4/+0) mm		6 mm	4.5 mm
No stock item (MOQ)	315223	Polystone® PPs EL black extruded	welding rod	welding rod	black, similar RAL 9005	B=5 (+/-0,3) x 3 (+/-0,3) mm		5 mm	3 mm
No stock item (MOQ)	358120	Polystone® PPs EL black extruded	welding rod	welding rod	black, similar RAL 9005	B=5,7 (-0,5/+0,1) x 3,8 (-0,4/+0) mm		5.7 mm	3.8 mm
No stock item (MOQ)	412555	Polystone® PPs EL black extruded	welding rod	welding rod	black, similar RAL 9005	B=5 (+/-0,3) x 3 (+/-0,3) mm		5 mm	3 mm
No stock item (MOQ)	416728	Polystone® PPs EL black extruded	welding rod	welding rod	black, similar RAL 9005	2.000 x 5 (+/-0,3) x 3,5 (-0,4/+0) mm	2,000 mm	5 mm	3.5 mm
No stock item (MOQ)	451630	Polystone® PPs EL black extruded	welding rod	welding rod	black, similar RAL 9005	2000 x 5 (+/-0,3) x 3,2 (-0,4/+0) mm	2,000 mm	5 mm	3.2 mm
No stock item (MOQ)	459386	Polystone® PPs EL black extruded	sheet	sheet	black, similar RAL 9005	3 x 1500 x 3000 mm	3,000 mm	1,500 mm	3 mm
No stock item (MOQ)	478329	Polystone® PPs EL black extruded	sheet	sheet	black, similar RAL 9005	3 x 1500 x 3000 mm	3,000 mm	1,500 mm	3 mm
No stock item (MOQ)	244904	Polystone® PPs EL black pressed	sheet	sheet	black, similar RAL 9005	20 (+1,5/) x 1000 x 2000 mm	2,000 mm	1,000 mm	20 mm
No stock item (MOQ)	244906	Polystone® PPs EL black pressed	sheet	sheet	black, similar RAL 9005	30 (+1,5/) x 1000 x 2000 mm	2,000 mm	1,000 mm	30 mm
No stock item (MOQ)	244907	Polystone® PPs EL black pressed	sheet	sheet	black, similar RAL 9005	20 x 1000 x 2000 mm	2,000 mm	1,000 mm	20 mm
No stock item (MOQ)	244909	Polystone® PPs EL black pressed	sheet	sheet	black, similar RAL 9005	30 x 1000 x 2000 mm	2,000 mm	1,000 mm	30 mm
No stock item (MOQ)	301480	Polystone® PPs EL black pressed	sheet	sheet	black, similar RAL 9005	40 x 1000 x 2000 mm	2,000 mm	1,000 mm	40 mm
No stock item (MOQ)	301504	Polystone® PPs EL black pressed	sheet	sheet	black, similar RAL 9005	40 (+1,5/) x 1000 x 2000 mm	2,000 mm	1,000 mm	40 mm
No stock item (MOQ)	312849	Polystone® PPs EL black pressed	sheet	sheet	black, similar RAL 9005	12 x 2000 x 6000 mm	6,000 mm	2,000 mm	12 mm
No stock item (MOQ)	312850	Polystone® PPs EL black pressed	sheet	sheet	black, similar RAL 9005	12 (+1,5/) x 2000 x 6000 mm	6,000 mm	2,000 mm	12 mm
No stock item (MOQ)	313800	Polystone® PPs EL black pressed	sheet	sheet	black, similar RAL 9005	20 x 2000 x 6000 mm	6,000 mm	2,000 mm	20 mm
No stock item (MOQ)	313801	Polystone® PPs EL black pressed	sheet	sheet	black, similar RAL 9005	20 (+1,5/) x 2000 x 6000 mm	6,000 mm	2,000 mm	20 mm
No stock item (MOQ)	316202	Polystone® PPs EL black pressed	sheet	sheet	black, similar RAL 9005	15 x 1000 x 2000 mm	2,000 mm	1,000 mm	15 mm
No stock item (MOQ)	316301	Polystone® PPs EL black pressed	sheet	sheet	black, similar RAL 9005	15 (+1,5/) x 1000 x 2000 mm	2,000 mm	1,000 mm	15 mm
No stock item (MOQ)	316669	Polystone® PPs EL black pressed	sheet	sheet	black, similar RAL 9005	15 x 2000 x 6000 mm	6,000 mm	2,000 mm	15 mm
No stock item (MOQ)	316670	Polystone® PPs EL black pressed	sheet	sheet	black, similar RAL 9005	15 (+1,5/) x 2000 x 6000 mm	6,000 mm	2,000 mm	15 mm
No stock item (MOQ)	371364	Polystone® PPs EL black pressed	sheet	sheet	black, similar RAL 9005	12 x 1000 x 2000 mm	2,000 mm	1,000 mm	12 mm
No stock item (MOQ)	371488	Polystone® PPs EL black pressed	sheet	sheet	black, similar RAL 9005	100 x 1000 x 2000 mm	2,000 mm	1,000 mm	100 mm
No stock item (MOQ)	371501	Polystone® PPs EL black pressed	sheet	sheet	black, similar RAL 9005	100 (+1,5/) x 1000 x 2000 mm	2,000 mm	1,000 mm	100 mm
No stock item (MOQ)	383255	Polystone® PPs EL black pressed	sheet	sheet	black, similar RAL 9005	60 x 1000 x 2000 mm	2,000 mm	1,000 mm	60 mm
No stock item (MOQ)	383329	Polystone® PPs EL black pressed	sheet	sheet	black, similar RAL 9005	60 (+1,5/) x 1000 x 2000 mm	2,000 mm	1,000 mm	60 mm
No stock item (MOQ)	401474	Polystone® PPs EL black pressed	sheet	sheet	black, similar RAL 9005	70 x 1000 x 2000 mm	2,000 mm	1,000 mm	70 mm
No stock item (MOQ)	410208	Polystone® PPs EL black pressed	sheet	sheet	black, similar RAL 9005	50 x 1000 x 2000 mm	2,000 mm	1,000 mm	50 mm
No stock item (MOQ)	410222	Polystone® PPs EL black pressed	sheet	sheet	black, similar RAL 9005	50 (+1,5/) x 1000 x 2000 mm	2,000 mm	1,000 mm	50 mm

Technical Specifications Polystone® PPs EL black extruded

	Test Method	Unit	Guideline Value
Density	DIN EN ISO 1183-1	g / cm³	>1,17
Flammability (Thickness 3 mm / 6 mm)	UL 94		V0

	Test Method	Unit	Guideline Value
Yield stress	DIN EN ISO 527	MPa	>20
Tensile modulus of elasticity	DIN EN ISO 527	MPa	>1300
Notched impact strength	DIN EN ISO 179	kJ / m²	>4
Shore hardness	DIN EN ISO 868	scale D	>65

	Test Method	Unit	Guideline Value
Melting temperature	ISO 11357-3	°C	>145
Thermal conductivity	DIN 52612-1	W / (m * K)	0,22
Thermal capacity	DIN 52612	kJ / (kg * K)	1,70
Coefficient of linear thermal expansion	DIN 53752	10^-6 / K	120 ... 190
Service temperature, long term	Average	°C	0 … 100
Service temperature, short term (max.)	Average	°C	130
Vicat softening temperature	DIN EN ISO 306, Vicat B	°C	81

	Test Method	Unit	Guideline Value
Volume resistivity	DIN EN 62631-3-1	Ω * cm	10⁵
Surface resistivity	DIN EN 62631-3-2	Ω	10⁵

Technical Specifications Polystone® PPs EL black pressed

	Test Method	Unit	Guideline Value
Density	DIN EN ISO 1183-1	g / cm³	>1,17
Flammability (Thickness 3 mm / 6 mm)	UL 94		V0

	Test Method	Unit	Guideline Value
Yield stress	DIN EN ISO 527	MPa	>20
Tensile modulus of elasticity	DIN EN ISO 527	MPa	>1300
Notched impact strength	DIN EN ISO 179	kJ / m²	>4
Shore hardness	DIN EN ISO 868	scale D	>65

	Test Method	Unit	Guideline Value
Melting temperature	ISO 11357-3	°C	>145
Thermal conductivity	DIN 52612-1	W / (m * K)	0,22
Thermal capacity	DIN 52612	kJ / (kg * K)	1,70
Coefficient of linear thermal expansion	DIN 53752	10^-6 / K	120 ... 190
Service temperature, long term	Average	°C	0 … 100
Service temperature, short term (max.)	Average	°C	130
Vicat softening temperature	DIN EN ISO 306, Vicat B	°C	81

	Test Method	Unit	Guideline Value
Volume resistivity	DIN EN 62631-3-1	Ω * cm	10⁵
Surface resistivity	DIN EN 62631-3-2	Ω	10⁵

Downloads

Technical Data Sheet Polystone® PPs EL black extruded

Technical Data Sheet Polystone® PPs EL black pressed

Product Handling Information Sheet Polystone® PPs EL black extruded

Product Handling Information Sheet Polystone® PPs EL black pressed

Brochure - Chemical Processing - CZ

Brochure - Chemical Processing - ES

Brochure - Chemical processing industry Chemischer Behaelter und Anlagenbau - DE

Brochure - Chemical processing industry - EN

Brochure - Chemical processing - IT

Brochure - Chemical processing - ZH

Brochure - Projektreport Industrial Galvanic plants - DE EN
