Trovidur® EC N grey

PVC-U

T-6702 greyT-231 greyT-7011 iron grey
sheetwelding rod
QR-Code

Characteristics

  • Good resistance to acids, lyes and salt solutions
  • Good weldability
  • Good glueability
  • Electrically insulating
  • Easy processing
  • Vacuum formable
  • Self-Extinguishing after removal of the flame
  • Good impact strength

Industries

Application Examples

+

通风系统中的液滴分离器

在压缩空气式刮水器中，始终有针对腐蚀性气体的空气清洗器，它由耐化学腐蚀的材料 Trovidur® EC-N（PVC-U）制成。Trovidur® EC 是一种具有普通耐冲击能力的 PVC，不含软化剂。

+

A solution for safe and modular battery housing

For their high-voltage battery in the electric race car, the students developed a modular internal structure based on a load-bearing housing. Inside, specially designed mounting boxes made of flame-retardant and electrically insulating PVC are used – manufactured from sheet material supplied by Röchling Industrial.

Variants

Show product in Webshop
SKUNameTypeTypeColorMeasurementsLengthWidthThicknessHeight
Stock item (no MOQ)		100714Trovidur® EC N grey extruded sheet sheet T-6702 grey3 x 1500 x 3000 mm 3,000 mm 1,500 mm 3 mm
Stock item (no MOQ)		100715Trovidur® EC N grey extruded sheet sheet T-231 grey20 x 1000 x 2000 mm 2,000 mm 1,000 mm 20 mm
Stock item (no MOQ)		100774Trovidur® EC N grey extruded sheet sheet T-231 grey1 x 1000 x 2000 mm 2,000 mm 1,000 mm 1 mm
Stock item (no MOQ)		100775Trovidur® EC N grey extruded sheet sheet T-231 grey2 x 1000 x 2000 mm 2,000 mm 1,000 mm 2 mm
Stock item (no MOQ)		100776Trovidur® EC N grey extruded sheet sheet T-231 grey3 x 1000 x 2000 mm 2,000 mm 1,000 mm 3 mm
Stock item (no MOQ)		100777Trovidur® EC N grey extruded sheet sheet T-231 grey4 x 1000 x 2000 mm 2,000 mm 1,000 mm 4 mm
Stock item (no MOQ)		100778Trovidur® EC N grey extruded sheet sheet T-231 grey5 x 1000 x 2000 mm 2,000 mm 1,000 mm 5 mm
Stock item (no MOQ)		100779Trovidur® EC N grey extruded sheet sheet T-231 grey6 x 1000 x 2000 mm 2,000 mm 1,000 mm 6 mm
Stock item (no MOQ)		100780Trovidur® EC N grey extruded sheet sheet T-231 grey8 x 1000 x 2000 mm 2,000 mm 1,000 mm 8 mm
Stock item (no MOQ)		100781Trovidur® EC N grey extruded sheet sheet T-231 grey10 x 1000 x 2000 mm 2,000 mm 1,000 mm 10 mm
Stock item (no MOQ)		100782Trovidur® EC N grey extruded sheet sheet T-231 grey12 x 1000 x 2000 mm 2,000 mm 1,000 mm 12 mm
Stock item (no MOQ)		100783Trovidur® EC N grey extruded sheet sheet T-231 grey15 x 1000 x 2000 mm 2,000 mm 1,000 mm 15 mm
Stock item (no MOQ)		100784Trovidur® EC N grey extruded sheet sheet T-231 grey3 x 1500 x 3000 mm 3,000 mm 1,500 mm 3 mm
Stock item (no MOQ)		100785Trovidur® EC N grey extruded sheet sheet T-231 grey4 x 1500 x 3000 mm 3,000 mm 1,500 mm 4 mm
Stock item (no MOQ)		100786Trovidur® EC N grey extruded sheet sheet T-231 grey5 x 1500 x 3000 mm 3,000 mm 1,500 mm 5 mm
Stock item (no MOQ)		100787Trovidur® EC N grey extruded sheet sheet T-231 grey6 x 1500 x 3000 mm 3,000 mm 1,500 mm 6 mm
Stock item (no MOQ)		100788Trovidur® EC N grey extruded sheet sheet T-231 grey8 x 1500 x 3000 mm 3,000 mm 1,500 mm 8 mm
Stock item (no MOQ)		100789Trovidur® EC N grey extruded sheet sheet T-231 grey10 x 1500 x 3000 mm 3,000 mm 1,500 mm 10 mm
No stock item (MOQ)		100790Trovidur® EC N grey extruded sheet sheet T-6702 grey2 x 1500 x 3000 mm 3,000 mm 1,500 mm 2 mm
Stock item (no MOQ)		100792Trovidur® EC N grey extruded sheet sheet T-6702 grey5 x 1500 x 3000 mm 3,000 mm 1,500 mm 5 mm
Stock item (no MOQ)		100876Trovidur® EC N grey extruded sheet sheet T-7011 iron grey3 x 1220 x 2440 mm 2,440 mm 1,220 mm 3 mm
Stock item (no MOQ)		100882Trovidur® EC N grey extruded sheet sheet T-7011 iron grey1 x 1000 x 2000 mm 2,000 mm 1,000 mm 1 mm
Stock item (no MOQ)		100883Trovidur® EC N grey extruded sheet sheet T-7011 iron grey1,5 x 1000 x 2000 mm 2,000 mm 1,000 mm 1.5 mm
Stock item (no MOQ)		100884Trovidur® EC N grey extruded sheet sheet T-7011 iron grey2 x 1000 x 2000 mm 2,000 mm 1,000 mm 2 mm
Stock item (no MOQ)		100885Trovidur® EC N grey extruded sheet sheet T-7011 iron grey3 x 1000 x 2000 mm 2,000 mm 1,000 mm 3 mm
Stock item (no MOQ)		100886Trovidur® EC N grey extruded sheet sheet T-7011 iron grey4 x 1000 x 2000 mm 2,000 mm 1,000 mm 4 mm
Stock item (no MOQ)		100887Trovidur® EC N grey extruded sheet sheet T-7011 iron grey5 x 1000 x 2000 mm 2,000 mm 1,000 mm 5 mm
Stock item (no MOQ)		100888Trovidur® EC N grey extruded sheet sheet T-7011 iron grey6 x 1000 x 2000 mm 2,000 mm 1,000 mm 6 mm
Stock item (no MOQ)		100889Trovidur® EC N grey extruded sheet sheet T-7011 iron grey8 x 1000 x 2000 mm 2,000 mm 1,000 mm 8 mm
Stock item (no MOQ)		100890Trovidur® EC N grey extruded sheet sheet T-7011 iron grey10 x 1000 x 2000 mm 2,000 mm 1,000 mm 10 mm
Stock item (no MOQ)		100891Trovidur® EC N grey extruded sheet sheet T-7011 iron grey12 x 1000 x 2000 mm 2,000 mm 1,000 mm 12 mm
Stock item (no MOQ)		100892Trovidur® EC N grey extruded sheet sheet T-7011 iron grey15 x 1000 x 2000 mm 2,000 mm 1,000 mm 15 mm
Stock item (no MOQ)		100893Trovidur® EC N grey extruded sheet sheet T-7011 iron grey20 x 1000 x 2000 mm 2,000 mm 1,000 mm 20 mm
Stock item (no MOQ)		100894Trovidur® EC N grey extruded sheet sheet T-7011 iron grey25 x 1000 x 2000 mm 2,000 mm 1,000 mm 25 mm
Stock item (no MOQ)		100895Trovidur® EC N grey extruded sheet sheet T-7011 iron grey30 x 1000 x 2000 mm 2,000 mm 1,000 mm 30 mm
Stock item (no MOQ)		100896Trovidur® EC N grey extruded sheet sheet T-7011 iron grey40 x 1000 x 2000 mm 2,000 mm 1,000 mm 40 mm
Stock item (no MOQ)		100897Trovidur® EC N grey extruded sheet sheet T-7011 iron grey2 x 1500 x 3000 mm 3,000 mm 1,500 mm 2 mm
Stock item (no MOQ)		100898Trovidur® EC N grey extruded sheet sheet T-7011 iron grey3 x 1500 x 3000 mm 3,000 mm 1,500 mm 3 mm
Stock item (no MOQ)		100899Trovidur® EC N grey extruded sheet sheet T-7011 iron grey4 x 1500 x 3000 mm 3,000 mm 1,500 mm 4 mm
Stock item (no MOQ)		100900Trovidur® EC N grey extruded sheet sheet T-7011 iron grey5 x 1500 x 3000 mm 3,000 mm 1,500 mm 5 mm
Stock item (no MOQ)		100901Trovidur® EC N grey extruded sheet sheet T-7011 iron grey6 x 1500 x 3000 mm 3,000 mm 1,500 mm 6 mm
Stock item (no MOQ)		100902Trovidur® EC N grey extruded sheet sheet T-7011 iron grey8 x 1500 x 3000 mm 3,000 mm 1,500 mm 8 mm
Stock item (no MOQ)		100903Trovidur® EC N grey extruded sheet sheet T-7011 iron grey10 x 1500 x 3000 mm 3,000 mm 1,500 mm 10 mm
Stock item (no MOQ)		100904Trovidur® EC N grey extruded sheet sheet T-7011 iron grey12 x 1500 x 3000 mm 3,000 mm 1,500 mm 12 mm
Stock item (no MOQ)		100905Trovidur® EC N grey extruded sheet sheet T-7011 iron grey15 x 1500 x 3000 mm 3,000 mm 1,500 mm 15 mm
Stock item (no MOQ)		100906Trovidur® EC N grey extruded sheet sheet T-7011 iron grey20 x 1500 x 3000 mm 3,000 mm 1,500 mm 20 mm
Stock item (no MOQ)		100907Trovidur® EC N grey extruded sheet sheet T-7011 iron grey25 x 1500 x 3000 mm 3,000 mm 1,500 mm 25 mm
Stock item (no MOQ)		100937Trovidur® EC N grey extruded sheet sheet T-7011 iron grey9 x 1220 x 2440 mm 2,440 mm 1,220 mm 9 mm
Stock item (no MOQ)		100938Trovidur® EC N grey extruded sheet sheet T-7011 iron grey35 x 1000 x 2000 mm 2,000 mm 1,000 mm 35 mm
Stock item (no MOQ)		101299Trovidur® EC N grey extruded welding rod welding rod T-7011 iron greyØ 3 x 1.000 mm 1,000 mm 3 mm
Stock item (no MOQ)		101301Trovidur® EC N grey extruded welding rod welding rod T-7011 iron grey2.000 x 4,3 x 3 mm 2,000 mm 4.3 mm 3 mm
Stock item (no MOQ)		101302Trovidur® EC N grey extruded welding rod welding rod T-7011 iron grey2.000 x 6 x 4,5 mm 2,000 mm 6 mm 4.5 mm
Stock item (no MOQ)		101310Trovidur® EC N grey extruded welding rod welding rod T-231 greyØ 4 x 1.000 mm 1,000 mm 4 mm
Stock item (no MOQ)		101313Trovidur® EC N grey extruded welding rod welding rod T-7011 iron greyØ 4 x 1.000 mm 1,000 mm 4 mm
Stock item (no MOQ)		101324Trovidur® EC N grey extruded welding rod welding rod T-231 greyØ 3 x 1.000 mm 1,000 mm 3 mm
Stock item (no MOQ)		101325Trovidur® EC N grey extruded welding rod welding rod T-7011 iron greyØ 3 mm 3 mm
Stock item (no MOQ)		101413Trovidur® EC N grey extruded welding rod welding rod T-7011 iron greyØ 2 x 1.000 mm 1,000 mm 2 mm
Stock item (no MOQ)		101414Trovidur® EC N grey extruded welding rod welding rod T-7011 iron grey2.000 x 7 x 5,3 mm 2,000 mm 7 mm 5.3 mm
Stock item (no MOQ)		101416Trovidur® EC N grey extruded sheet sheet T-7011 iron grey1,5 x 1220 x 2440 mm 2,440 mm 1,220 mm 1.5 mm
Stock item (no MOQ)		101417Trovidur® EC N grey extruded welding rod welding rod T-231 grey2.000 x 4,3 x 3 mm 2,000 mm 4.3 mm 3 mm
Stock item (no MOQ)		207109Trovidur® EC N grey extruded sheet sheet T-7011 iron grey30 x 1500 x 3000 mm 3,000 mm 1,500 mm 30 mm
Stock item (no MOQ)		222298Trovidur® EC N grey extruded sheet sheet T-7011 iron grey12 x 1220 x 2440 mm 2,440 mm 1,220 mm 12 mm
Stock item (no MOQ)		222299Trovidur® EC N grey extruded sheet sheet T-7011 iron grey15 x 1220 x 2440 mm 2,440 mm 1,220 mm 15 mm
Stock item (no MOQ)		303205Trovidur® EC N grey extruded sheet sheet T-7011 iron grey4,5 x 1500 x 3000 mm 3,000 mm 1,500 mm 4.5 mm
Stock item (no MOQ)		306171Trovidur® EC N grey extruded sheet sheet T-7011 iron grey6 x 1220 x 2440 mm 2,440 mm 1,220 mm 6 mm
Stock item (no MOQ)		308349Trovidur® EC N grey extruded sheet sheet T-7011 iron grey4,5 x 1220 x 2440 mm 2,440 mm 1,220 mm 4.5 mm
Stock item (no MOQ)		333114Trovidur® EC N grey extruded sheet sheet T-7011 iron grey50 x 1000 x 2000 mm 2,000 mm 1,000 mm 50 mm
Stock item (no MOQ)		338866Trovidur® EC N grey extruded sheet sheet T-7011 iron grey9 x 1500 x 3000 mm 3,000 mm 1,500 mm 9 mm
Stock item (no MOQ)		350073Trovidur® EC N grey extruded sheet sheet T-7011 iron grey25 x 1220 x 2440 mm 2,440 mm 1,220 mm 25 mm
Stock item (no MOQ)		351432Trovidur® EC N grey extruded sheet sheet T-7011 iron grey18 x 1220 x 2440 mm 2,440 mm 1,220 mm 18 mm

Technical Specifications Trovidur® EC N grey

Test MethodUnitGuideline Value
DensityDIN EN ISO 1183-1g / cm31,44
Water absorptionDIN EN ISO 62%0,2
Flammability (Thickness 1 ... 4 mm)DIN 4102B1
Flammability from 3 mmUL 94V0, 5VA
Flammability from 1 mmUL 94V0, 5VB
Flammability (Thickness 1 ... 10 mm)NF P 92-501M1
Flammability (Thickness 1,5 ... 12 mm)BS 476 Part 6Class 0
Flammability (Thickness 1,5 ... 12 mm)BS 476 Part 7Class 1
Flammability (Thickness 1,5 ... 6 mm)EN 13501-1B -s3d0
WRAS (Thickness 1 ... 6 mm), greyBS6920-1listed

Test MethodUnitGuideline Value
Yield stressDIN EN ISO 527MPa55
Elongation at breakDIN EN ISO 527%20
Tensile modulus of elasticityDIN EN ISO 527MPa3000
Notched impact strengthDIN EN ISO 179kJ / m24
Shore hardnessDIN EN ISO 868scale D82
Ball indentation hardnessDIN EN ISO 2039-1MPa110
Compressive strengthDIN EN ISO 604MPa75
Bending strengthDIN EN ISO 178MPa80

Test MethodUnitGuideline Value
Thermal conductivityDIN EN ISO 8302W / (m * K)0,16
Vicat softening temperatureDIN EN ISO 306, Vicat B°C75
Service Temperature°C- 15 ... + 60
Heat deflection temperatureDIN EN ISO 75°C68
Coefficient of linear thermal expansionDIN EN ISO 11359-2mm/m K∼ 0,075
Glow wire ignition tempeartureDIN EN 60695-2-13°C925
Glow wire flammability indexDIN EN 60695-2-12°C960

Test MethodUnitGuideline Value
Dielectric constantIEC 60250∼ 3,2
Dielectric dissipation factor (106 Hz)IEC 60250∼ 0,02
Volume resistivityDIN EN 62631-3-1Ω * cm>1015
Surface resistivityDIN EN 62631-3-2Ω>1013
Dielectric strengthIEC 60243kV / mm12
Comparative tracking indexIEC 60112CTI600
